Tolerances and Standards

CNC Machining Tolerances

Standard Tolerance

General machining tolerance for non-critical dimensions, suitable for most commercial parts.

Tolerance

±0.125mm (0.005")

Fine Tolerance

Achievable with standard tooling and careful setup, ideal for precision components.

Tolerance

±0.025mm (0.001")

Super Fine Tolerance

Requires specialized tooling and fixturing, for critical aerospace and medical parts.

Tolerance

±0.005mm (0.0002")

Linear Dimension

Standard linear dimension tolerance for machined features up to 500mm.

Tolerance

±0.050mm

H

Hole Diameter

Drilled and reamed hole tolerance with standard tooling.

Tolerance

±0.025mm

S

Surface Finish (Ra)

Standard machined surface finish without secondary operations.

Tolerance

0.8-3.2 μm

T

Thread Tolerance

Standard thread tolerance for tapped holes and external threads.

Tolerance

Class 6H / 6g

F

Flatness

Flatness tolerance for milled surfaces within 100mm x 100mm area.

Tolerance

±0.020mm

3D Printing Tolerances

SLS Nylon Standard

Selective Laser Sintering tolerance for general-purpose nylon parts.

Tolerance

±0.3mm (0.012")

SLA Resin Fine

Stereolithography tolerance for high-detail resin prototypes.

Tolerance

±0.1mm (0.004")

F

FDM Standard

Fused Deposition Modeling tolerance for PLA/ABS prototype parts.

Tolerance

±0.5mm (0.02")

M

MJF Nylon

Multi Jet Fusion tolerance for production-grade nylon parts.

Tolerance

±0.2mm (0.008")

Metal DMLS

Direct Metal Laser Sintering tolerance for metal 3D printed parts.

Tolerance

±0.1mm (0.004")

L

Layer Thickness

Minimum layer thickness achievable across different technologies.

Tolerance

0.05-0.3mm

Injection Molding Tolerances

Commercial Tolerance

Standard commercial molding tolerance suitable for consumer products.

Tolerance

±0.25mm (0.01")

Fine Tolerance

Precision molding tolerance with optimized tool design and process.

Tolerance

±0.05mm (0.002")

S

Shrinkage Allowance

Typical shrinkage compensation for common thermoplastics.

Tolerance

0.2-2.5%

P

Parting Line Tolerance

Flash and parting line tolerance for standard injection molds.

Tolerance

±0.10mm

D

Draft Angle

Recommended draft angle for easy part ejection.

Tolerance

0.5°-3°

W

Wall Thickness

Minimum and recommended wall thickness for injection molded parts.

Tolerance

1.0-3.0mm

Sheet Metal Tolerances

Linear Dimension

Standard tolerance for linear dimensions on sheet metal parts.

Tolerance

±0.20mm

B

Bend Angle

Typical bend angle tolerance for press brake forming.

Tolerance

±1.0°

B

Bend to Edge

Tolerance from bend line to part edge after forming.

Tolerance

±0.25mm

H

Hole to Edge

Minimum distance and tolerance from hole center to part edge.

Tolerance

±0.15mm

F

Flatness

Flatness tolerance for sheet metal parts within 500mm x 500mm.

Tolerance

±0.50mm

K

K-Factor

Standard K-factor for bend allowance calculations in sheet metal.

Tolerance

0.35-0.50
